Hi all,
I am using the EVAL-M3-302F controller board with the EVAL-M3-IM564 driver board.
I filled out everything in the MCEWizard and I generated my designer file. When I open the MCEDesigner and upload the file to the board, I get an PFC Fault: PFC Gatekill.
I've checked and I don't think it's overcurrent and I used the correct shunt setup (single shunt). I am a little lost, so if anyone has any idea what the problem might be, please let me know.
I have added my mc2 file and irc file in the zipped folder.
Best regards,
Mike
Show LessHello,
The three phase inverter simulation for the CIPOS IPM line is not working again. Ive tried different browsers, networks and computers as well as my phone. Is there a way I can get this working ASAP?
It was working before, i see the landing page at least but it has no simulation tools.
Show LessHello, I can't imagine how the value of output current per leg in parameters calculated, so i need a help for knowing that.
Attached a screenshot from parameter table.
Thanks!
Show Less
I bought the KIT_6W_18V_P7_950V, but the output 18V does not meet my needs, I want to change the output voltage to 15V, how should I modify the circuit?
Show Less
Hello expert;
vdd=16V
Itrip pin is null
P=20V (dc bara)
HınA(PIN7=%100 duty cycle
LınA(PIN9)=%50 duty cycle
firstly I will drive Dc motor,after that SRM
I don't obtain HA-LA (output voltage)(phase)
There seems to be very little tension
Is the error caused by the bootstrap diode or is there a switching problem?
I added a diode externally if the one inside does not work
what should I do?
I need the help.
I use a diff probe for measurement.
If you give your e-mail address, I can send you schematic drawings and PWM signals.
Thank you
Best regards...
Show LessBTS7010-2EPA according to the reference circuit design, the input PWM signal, the design requirements are, through the input duty cycle changes, open to adjust the output duty cycle, but the actual test situation, the input duty cycle changes, the output does not change, the output of the chip supply voltage of 12V, this is why it is, is not the chip was originally so!
smartconx_target@Q!w2e3r4t5y6u7i8o9p0||/t5/%E6%99%BA%E8%83%BD%E5%8A%9F%E7%8E%87%E6%A8%A1%E5%9D%97/BTS7010-2EPA%E9%A9%B1%E5%8A%A8%E7%9B%B8%E5%85%B3%E9%97%AE%E9%A2%98/td-p/699437
Show LessCan you tell me how to calculate the maximum current value of a load that can be driven by a multiple high-side chip such as BTS7040-2EPA? For example, is it possible to drive two 3.5A loads at the same time?
smartconx_target@Q!w2e3r4t5y6u7i8o9p0||/t5/%E6%99%BA%E8%83%BD%E5%8A%9F%E7%8E%87%E6%A8%A1%E5%9D%97/%E5%A6%82%E4%BD%95%E8%AE%A1%E7%AE%97BTS7040-2EPA%E8%83%BD%E5%A4%9F%E9%A9%B1%E5%8A%A8%E7%9A%84%E6%9C%80%E5%A4%A7%E8%B4%9F%E8%BD%BD%E7%94%B5%E6%B5%81%E5%80%BC/td-p/698661
Show LessHello There,
I hoe you are doing well.
I have a question, I saw the specification of IM323-L6G2 as below
Pmot= 1200w
The question is :
how is this IPM (IM323-L6G2) used in EVAL-M1-IM323 that is its max output power =1500w not 1200w ?
Best Regards,
Tawfik
Show LessI am looking for an evaluation board to investigate the use of a ~3hp interior permanent magnet (IPM) motor for a treadmill application.
It looks like the EVAL-M3-IM564 power board + the EVAL-M3-102T fits my needs but I would like to know if there are other Eval kit options available that may work as well.
Show Less下記ANの6.4項に Heatsink methodsについての記載がございます。 こちらのANはIRSM5xxとIM240についてのものだと思いますが、IM241にも適用可能でしょうか?
